Casting Bronze Bearings , Strengthening Brass With Solid Lubricant Casting Bronze Bearings

Name: Casting Bronze Bearings Strengthening Brass With Solid Lubricant Casting Bronze Bearings
Brand: TOB Casting Bronze Bearings
Price: 1 USD

Quality Casting Bronze Bearings , Strengthening Brass With Solid Lubricant Casting Bronze Bearings for sale

MOQ : negotiated

Payment Terms : T/T

Delivery Time : negotiated

Packaging Details : Cartons or Pallets

Brand Name : TOB Casting Bronze Bearings

Certification : ISO 16949

Place of Origin : China

Price : negotiated

Supply Ability : negotiated

Material : Strengthening Brass With Solid Lubricant

Application : consecutive casting and rolling machines, mine-exploiting equipment, ships, steam engine, etc.

Types : Cylinder Bearings, Thrust Washer, Slide Block, etc.

Name : JDB Bearing, OILES 500# Bearing, Solid Lubricating Bearings

Hardness : ≥210 HB

Working Temperature Limits : -40~+300℃

Contact Now

Strengthening Brass With Solid Lubricant Casting Bronze Bearings

Strengthening Brass + Solid Lubricant Bearings is backed with strengthening brass that has good physical performance and good capability for casting.

What’s more, the brass backing has pretty good anti-erosion ability in air, fresh water and seawater. The surface is regularly and finely machined with sockets in which particular solid lubricant is filled. Strengthening Brass + Solid Lubricant Bearings is widely used on consecutive casting and rolling machines, mine-exploiting equipment, ships, steam engine, etc.

Chemical Compositions

Product NO.	Chemical Compositions
TOB 050	Cu	Zn	Al	Fe	Mn	Si	Ni	Sn	Pb
TOB 050	60~66	22~28	5.0~8.0	2.0~4.0	2.5~5.0	<0.1	<0.5	<0.2	<0.2

Physical and Mechanical Performance

Performance Index		Data	Performance Index			Data
Density	g/cm³	8.2	Hardness		HB	≥210
Linear Expansion Coefficient	10^-5/℃	1.6-2.0	Flexibility Coefficient		KN/mm²	120-140
Heat-conducting Coefficient	W/(m·k)	38-55	Tensility		%	≥12
Tensile Strength	N/mm²	≥755	Friction	Oil Lubrication	μ	0.03
Anti-compact Tenacity	≥KJ/m^3	400-500	Friction	Dry Friction	μ	0.16

Application Condition Limits

Lubrication Conditions		Non- Lubrication	Periodical Lubrication	Consecutive Lubrication
Working Temperature Limits	℃	-40~+300	-40~+150	-40~+150
Max. Load pressure	N/mm²	100	100	100
Max. Linear Velocity	m/s	0.50	1.00	1.50
Max. PV Value	N/mm²·m/s	1.65	3.25	3.25

Casting Bronze Bearings , Strengthening Brass With Solid Lubricant Casting Bronze Bearings
